Viewable Size |
55" diagonal |
|
Display Active Area |
1209.6 mm (W) x 680.4mm (H) (47.6“x 26.8“) |
|
Display Inactive Area (Left/Right/Top/Bottom) |
6.9 mm / 6.9 mm / 6.9 mm / 95.5 mm (0.3“ / 0.3“ / 0.3“ / 3.8“) |
|
Aspect Ratio |
16:09 |
|
Display Resolution |
1920 x 1080, full HD |
|
Display Type |
Active Matrix Organic Light-Emitting Diode (AMOLED) |
|
Surface Treatment |
ERO (Extended Ruggedness and Optics) using Corning® Gorilla Glass® |
|
Full Screen White Brightness |
150 cd/m² (typ.) |
|
Peak White Brightness |
400 cd/m² (typ.) |
|
Brightness, Uniformity |
20% |
|
Transmissivity |
38% |
|
Orientation |
Landscape, Portrait, Inverted (Ceiling Mount), Tabletop, Tiled |
|
Viewing Angle (typ) |
178° H,V |
|
Contrast Ratio (typ) |
>100k:1 |
|
Response Time (typ) |
<1 ms |
|
Palette |
1.073 billion colors (10-bit) |
|
Color Gamut |
120% of NTSC |
|
Pixels per inch (PPI) |
40 |
|
Pixel Pitch |
0.63 mm |
|
Frame Rate |
120Hz |
|
Video Inputs |
H-D-M-I x4, DisplayPort x1 |
|
External Connections |
LAN RJ45, RS232, IR, Keypad, AC Power In, USB-A, USB-B |
|
Audio Output |
PC Line Out, S/PDIF |
|
Dimensions (W x H x D) |
1223.4 mm x 796.5 mm x 300.8 mm (48.2“ x 31.4“ x 11.8“) |
|
Weight |
31.8 kg (70.0 lbs) |
|
Power Requirements |
100 to 240VAC |
|
Power Consumption (typ) |
97W (<1W standby) |
|
Power Consumption (max) |
300W |
|
Mount |
No |
|
Control and Monitoring |
IR, RS-232, LAN, Keypad |
|
Operating Temperature |
0º to 40ºC |
|
Humidity |
20-95% RH non-condensing |
|
Options / Features |
Fanless, optional tray. Tiling/Video Wall configurations possible through optional external processor. Standard mount. |
|
Warranty |
1 year |
|
Recommended Usage |
Up to 18 hours per day |
